SUCHLS104 Landscape Utility
The Channel Landscape Standard Utility Trailer from Diamond T is leading the industry with its design and functionality available as a Bumper Pull trailer.
Performance while pulling empty and with a load are reasons that make our SUCHLS104 an industry leader which include the following standard features:
- Rock Guard on Fenders
- Wrap Around Tongue
- 2″ x 8″ Pressure Treated Floor
- Wiring Sealed in Frame
- 4 D-rings Inside Trailer
- Tubing Tail Board w/ Sealed LED’s
- 100% Prime and Paint
- 2 Line Pinstriping
- 24” or 48” Expanded Metal Sides
- Reflective Tape
Specifications
- Coupler: 2 5/16″ Bulldog Style Cast
- Jacks: 2000# Swivel
- Safety Chains: 1/4″x31″
- Tongue: 4″ Channel
- Frame: 4” Channel Frame
- Toprail: 2”x2”x1/8” Angle
- Uprights: 2″x2″x1/8″ Angle
- Cross Members: 3”x2”x3/16” Angle 24” Spacing OC
- Axles: 1-5200# Idler, 1-5200# Brake w/ EZ Lube
- Suspension: 5 Leaf Double Eye
- Tires: ST 225/15 Load Range D Radial
- Wheels: 15″ 6 on 5 1/2″ Silver Mod
- Fenders: 9″x72″ w/ Radius Cut Back
- Body: 24” or 48” Expanded Metal Sides
- Lights: All Sealed LED Stop, Tail, Turn and Clearance
- Finish: Phosphate etched, primed, 2 coats acrylic enamel
Models
| 8314SUCHLS10424 | 83” W x 14’ L Landscape Standard Utility Channel Frame 104 w/ 24” sides |
| 8316SUCHLS10424 | 83” W x 16’ L Landscape Standard Utility Channel Frame 104 w/ 24” sides |
| 8318SUCHLS10424 | 83” W x 18’ L Landscape Standard Utility Channel Frame 104 w/ 24” sides |
| 8320SUCHLS10424 |
83” W x 20’ L Landscape Standard Utility Channel Frame 10 4 w/ 24” sides |
| 8314SUCHLS10448 | 83” W x 14’ L Landscape Standard Utility Channel Frame 104 w/ 48” sides |
| 8316SUCHLS10448 | 83” W x 16’ L Landscape Standard Utility Channel Frame 104 w/ 48” sides |
| 8318SUCHLS10448 | 83” W x 18’ L Landscape Standard Utility Channel Frame 104 w/ 48” sides |
| 8320SUCHLS10448 | 83” W x 20’ L Landscape Standard Utility Channel Frame 104 w/ 48” sides |
Options
AXLES
| 252BK | Two 5200# Electric Brake Axles |
RAMPS / DOVETAIL
| RGSA | Rear Gate Spring Assist |
GATES
| 83RG | 83″ Wide Fold Down Rear Gate 4′ tall (Lays flat on trailer floor) |
| SPTG | 77″ or 83″ Split Rear Tractor Gate with Spring Assist |
JACKS
| 7KSB | 7000# Set Back Mini Dropleg Jack |
COUPLER
| ADCP | 5 Position Channel with 2 5/16″ 15k Adjustable Coupler |
SPARE TIRE / WHEEL
| 2256H | ST 225/15 LRD w/6 on 5 1/2″ Silver Mod Spare Tire & Wheel |
ADDITIONAL OPTIONS
| PLSB | 24″ x 24″ Landscape Basket (Bolt-on) |
| BILSB | 24”x24” Landscape Basket Built-in 4’ Exp. Met. Side Trailer |
| 3WER | Weedeater Racks pr. (Welded-on 1 pr. Holds 3) |
| 3WERB | Weedeater Racks pr. (Bolt-on 1 pr. Holds 3) |
| STR | Spare Tire Rack |
| RDPF | 9″ x 72″ Teardrop 14g. Diamond Plate Fenders |
| SUPT | 2 3/8” 11 gauge Pipe Toprail |
| SUST | 2” 11 gauge Square Tube Toprail |
| FRLT | Front and Rear Fender Lights |
