Lowboy Equipment LEQ104
The Diamond T Lowboy Equipment trailer is leading the industry with its design and functionality that is available as a Bumper Pull Trailer. Performance while pulling empty and with a load are reasons that make our LEQ104 an industry leader which includes the following standard features:
- 3/8×2″Full Rubrail w/ Stakepockets
- Wrap Tongue on BP and GN
- Chain Tray in Tongue
- Tubing Tail Board w/ Sealed LED’s
- Sealed Factory Wiring Harness
- Spare Tire Rack
- 2′ Long Dovetail
- 12000# Side Handle Jack
- 100% Prime and Paint
- Spring Loaded Jack Foot
- 5′ Long 3″ Channel Spring Assist Knee Ramps
- DP Fenders w/ Teardrop
Specifications
- Coupler: 25/16″ Bulldog Style
- Jacks: 12000# Dropleg
- Safety Chains: 3/8″x39″ w/Sliphook
- Tongue: 5″ Channel
- Frame: 5″ Channel
- Front Bumprail: 2″ Square Tubing
- Front Uprights: 3″x2″x3/16″ Angle
- Cross Members: 3″ Channel 24″ OC
- Axles: 2-5200# Brake w/ EZ Lube
- Suspension: 5 Leaf Double Eye
- Tires: 235/16 ST Load Range E Radial
- Wheels: 16″ 6 on 5 1/2″ Silver Mod
- Fenders: 9″x72″ DP Dbl. Sq. Broke w/Back
- Flooring: 2×8 Pressure Treated Pine
- Lights: All Sealed LED Stop, Tail, Turn and Clearance
- Finish: Phosphate etched, primed, 2 coats acrylic enamel
Models
| 8314LEQ104 | 83″ W x 14′ Lowboy Equipment 104 |
| 8316LEQ104 | 83″ W x 16′ Lowboy Equipment 104 |
| 8318LEQ104 | 83″ W x 18′ Lowboy Equipment 104 |
| 8320LEQ104 | 83″ W x 20′ Lowboy Equipment 104 |
| 8322LEQ104 | 83″ W x 22′ Lowboy Equipment 104 |
| 8324LEQ104 | 83″ W x 24″ Lowboy Equipment 104 |
Options
RAMPS / DOVETAIL
| SLREX | 5′ Long 3″ Channel Ramps w/Slide-in Ramp Rack |
| LBDP2 | 2′ All Steel DP Dovetail |
| LBSA | Spring Assist For Knee Ramps |
COUPLER
| ADCP | 5 Position Channel with 2 5/16″ 15k Adjustable Coupler |
| ADPE | 5 Position Channel with 3″ Pintle Eye |
SPARE TIRE / WHEEL
| 2356H | 235/16 LRE w/6 on 5 1/2″ Silver Mod Spare Tire and Wheel |
UPGRADE TIRE/WHEEL
| 2356U | Upgrade to 235/16 LRE w/6 on 5 1/2″ Single Tire and Wheel |
FLOORING
| LBOF | Oak Floor up to 20′ Bed Length |
| LBEO | Oak Floor for each Foot of Bed Length over 20′ |
| DPSF | DP Steel Floor up to 20′ Bed Length |
| DPEF | DP Steel Floor for each 2′ of Bed Length over 20′ |
TOOL BOX
| LBNBAF | A-Frame Box in Bumper Pull |
ADDITIONAL OPTIONS
| LBTR | Fender Height Angle Toprail |
| FRLT | Front and Rear Fender Lights |
| 5LFSL | 5 Leaf Slipper Spring Suspension |
| 583DR | 5/8″ X 3″ D-Rings, Each Installed |
